12" SVGA color flat panel display, reprogrammable keypad , Intel Socket 370 Pentium III 1 GHz CPU, Four available expansion slots (2 PCI, 1 ISA, & 1 PCI or ISA), AGP graphics controller, 256 MB DRAM, NEMA 4/4X/12 front panel, CD-ROM, floppy, USB, 10/100 BaseT Ethernet, 100/240 V AC Power Supply, * 12.1" SVGA TFT color flat panel * 10/100 Base T Ethernet port * PS/2 keyboard and mouse port * VGA port (supports simultaneous display with additional monitor) * Four available expansion slots: Three ¾-length (1 PCI, 1 ISA, and 1 either ISA or PCI) * DOC 2000 socket upgrade * CD-ROM and Floppy with optional CD-R/W The 3612 CPU section easily removes from the front panel and display unit without having to detach the front panel from the NEMA enclosure. One connector is used to attach the entire front panel. The rear CPU section can be replaced with another very quickly. With the cover removed expansion cards are easily installed without cumbersome cables to contend with. The 3612 units have incorporated an easy access hard drive mount. Simply remove 2 screws and extract the hard drive. Remove the metal bracket and retention spring, attach it to the new hard drive and install your replacement The 3612 units have several options for the secondary IDE port on the CPU. The hard drive can be replaced with a dual hard drive unit for redundancy. If solid state storage media is desired than an externally accessible Type I or Type II CompactFlash option is available. |
