14" dia. x 41"-6" long mild steel screw conveyor. Unit has a 5hp 230/460 motor. It has a screw conveyor drive, not a shaft mount and unit drives a 2-7/16" dia shaft. There are three air operated discharges on the troughs and two or three loading points. Will continue to add info and pictures. The flights appear to be the equal of a Martin 14H508(helicoid) which has a 2-7/16" coupling dia. and the flights are 1/4"thk inside and 1/8"thk on edge which is what they now measure but have some wear. Conveyor is broken down in two pieces approx 21ft long.
|
