SEE A VIDEO ON YOUTUBE. COPY AND PASTE THE LINK BELOW! http://www.youtube.com/watch?v=-gIgNcWDsSQ Swing Over Bed 17.72" Swing Over Saddle 11.81" Swing Over Cross Slide 9.84" Maximum Turning Diameter 9.45" Maximum Turning Length 9.84" Hole Through Spindle 2.44" Spindle Nose A2-6" Spindle Speed 75 to 4,200 RPM Spindle Motor 20 HP Upper Turret 10 POSITION (VDI) Lower Turret 8 POSITION (VDI) Approximate Weight 11,800 lbs. Misc Tooling (Upper and Lower Turret) |
