Specifications:... Chuck Size 8" (2)... Max Diameter Bar Capacity 2"... Max Swing Over Bed 12.6"... Max Turning Diameter 8"... Distance Between Spindles 49.21"... Main Motor 20 / 15 HP... Spindle Speed 4,750 RPM... Tools 12 (2)... Spindle Bore 2.4"... Spindle Nose A2-6... Rapid Traverse Rates (X / Z) 1,200 / 1,300 IPM... X-Axis Travel 9.06"... Z-Axis Travel 19.69"... Turret Index (Single / Full Step) 0.5 / 1.4 Seconds... Machine Dimensions (L x W x H) 159.3" x 107" x 80.3"... Machine Weight 13,200 lbs... Equipped With: MAZATROL FUSION 640T CNC CONTROL... Conversational Programming... Twin Spindles & Twin Turrets... Parts Conveyor... (2) 8" Hydraulic Chucks... 10.4" Color LCD... 3.5" Floppy Disc Drive... 2 GB Hard Drive... High Power Coolant... Chip Conveyor (Rear Exit)...
|
