We are pleased to present the following for your consideration: HARDINGE CONQUEST 51 CNC TURNING CENTER W/LIVE TOOLING & BAR FEEDER MAXIMUM SWING OVER UPPER WAY COVER 21" MAXIMUM SWING OVER LOWER WAY COVER 14.5" MAX. TURNING DIA. / LENGTH 10.8" / 19.6" RAPID TRAVERSE RATE X / Z AXES 630 IPM SPINDLE BORE / BAR CAPACITY 2.4" / 2.0" TURRET CAPACITY (5 LIVE STATIONS) 10 STATION LIVE TOOLING SPEEDS 100 - 3,000 RPM MACHINE DIMENSIONS (APPROXIMATE) 122" x 54" x 68" MACHINE WEIGHT (APPROXIMATE) 10,000 LBS FANUC OTC CNC CONTROL WITH 9" MONOCHROME CRT RS-232C PORT INTERFACE FOR DNC OPERATION COLLET CHUCK WITH 2.0" CAPACITY ON MAIN SPINDLE SMW QS-7.52 SINGLE TUBE BARFEED UNIT WITH ACCESSORIES TOOL PRESETTER, EXTERNAL LIFT-UP TYPE CHIP CONVEYOR (4) LIVE TOOL HOLDERS (2 AXIAL & 2 RADIAL LIVE TOOL HOLDERS) ALL AVAILABLE TURNING TOOL BLOCK HOLDERS & WEDGES STANDARD COOLANT SYSTEM, ALL AVAILABLE MANAULS LOCATION: OUR WAREHOUSE; UNDER POWER (MILWAUKEE, WI) Whether you are in the market to sell your surplus equipment or purchase that hard-to-find machine, we have a knowledgeable staff that will strive to deliver quality products and services based on your needs, and assist you from start to finish. We don't just want your business; we want your repeat business. Thank You. |
