Evans - Model 4270 Laminate Rack w/ Model 4253 Index Table Equipment is located in Pensacola, FL Specs: 4270 - 135" L x 85" W x 60" H - Air Requirement 100 PSI Specs: 4253 - 73" x 162" Air Requirement 80 PSI Model R-RCGS-2-63-6 Quick Roller Coater Glue Spreader - 63" width capacity, 0-6" opening Roller Coater The top Roller is easily adjustable to the thickness of the work being laminated. Simply insert the provided spacer 1/8, 1/4, 1/2, and 3/4. This is specifically designed to laminate using either contact adhesives or the fast bond PVA's. This allow for uniformed and even bonding of the laminate to the substrate. Specs: 61" L x 28" W x 48" H - Drive motor 1/2 HP - Feed Rate 50 FPM - Electrical 110Volt - Air 100 PSI Complete laminating line including: 63" QUICK top and bottom glue spreader, EVANS Index Table, EVANS Pinch Roller. . 2005 EVANS "0256" Pinch Roller, 61.5" capacity, 4" opening, 100 PSI air pressure top roller, positive top roller adjustment, 5-1/2" dia. solid bottom roller; feed speed 50 FPM. 30" Bed height, welded 3/16" steel plate construction; includes safety gate; 1/2 HP drive, 110 V motor. . 2005 EVANS "4253" Index Table. Handles boards from 9" x 27" to 62" x 145"; semi automatic index/layup table to assist in the layup of glued cores with face & back laminates, designed to be used in conjunction with a Glue Spreader for Pinch Roller or Cold Press operations. The system features Heavy Duty construction, includes a hand crank for manual width adjustments, width opening indicator, width adjustment locking device with pneumatic brake; adjustable guides for board positioning, 18" infeed extensions, and leveling feet. The operator manually positions the back sheet and then, with the machine assisting, guides the glued core from the glue spreader into positon over the backer sheet. When the core reaches the indexed stops, the core drops into position on the back. The top sheet is manually applied & indexed to the board, and the operator manually pushes the layed up panel into the Pinch Roller. - Requires 80 PSI compressed air 63" Cap. top & bottom coater for direct application of coatings or adhesive, 8" dia. acid & heat resistant SBR rubber covered (grooved) application roll, flow controlled with 5.8" dia. chrome doctor roll. 2 HP fixed speed drive with 80 FPM, upper elevator 0.04" - 1 - 3/3"opening with manual hand wheel adjustment on each post. Complete with: Safety emergency stop wire and roll guard hood, all aluminum drip pan catches clean-up water. SOUTHWORTH Scissor Lift "LS 436",4,000 Lbs. cap., 24" x 66" platform; 36" vertical travel; 7-1/4" lowered height; 1 HP hydraulic pump w/ magnetic starter; foot pedal operated. If you have any questions regarding this equipment. Please contact our office @ between the hours of 8:00 a.m. - 4:30 p.m. eastern standard time. |
