Excellent condition. Sony LH51-2 DRO. Gray Mills coolant system with filter. Walker cermax 9 x 18" permanent magnetic chuck. Weight is about 4,000 pounds. Serial number is 523-1818-1239, model number 1818. Spindle 2 H.P. Direct Drive (Std) -0- Wheel size 7"O.D. x 1-1/4" Hole x 1/2" wide Speed 3600 RPM Maximum Table Speed 100 Ft./Min. Maximum Table Travel 23" Maximum Cross Travel 9-1/2" Feed increments (amt. at each table reversal) .010-.50" Handwheel dial reads to .0002" Fine feed knob reads to .0001" Maximum vertical travel of wheel slide 20" Rapid power positioning rate (Opt.) 32" Min. Reservoir capacity 18 gal. Hydraulic motor H.P. 2 H.P. Type of lubrication system Automatic-Metered Surface waviness .000025" Finish 5 Microinches Any questions please call John at 636-447521 or cell at . You may email also at . * All bills must be paid in full within seven days of notification of sale. We reserve the right to resell items that remain unpaid after 7 days. * All skidding and boxing of items sold is extra. * If arrangements are being made to pick up the item(s), storage will be charged beyond the initial 15 day period. |
