Super Titan Scissor Lift32,000 lb Capacity, 36" Travel15 1/2" Lowered Height, 51 1/2" Raised Height BRAND NEW, DIRECT FROM MANUFACTURERAUTHORIZED DISTRIBUTOR Product Number: 36LL32 Delivered to you in 10-15 Days(depending on production schedules) Super Titans are the "Big Boys" of the Autoquip line of scissor lifts. These units are capable of lifting tons of material and are fitted with oversize platforms to accomodate the largest of loads. The double set of scissor legs gives added stability for the larger platform sizes offered in this series. · Lubricated-for-life composite bearings on all pivot points · Solid steel legs (8", 10", or 12" x 1 1/2" thick) · Turned, ground, polished and hard-chromed axle pins · Double-wire braided hydraulic hoses · Velocity fuses on cylinders · Four-inch hydraulic rams with solid steel rods, hard · Built and designed in accordance with ANSI MH29.1 · Factory tested to 110% of capacity · Maintenance-free bearings, no greasing · Minimal platform deflection · Extended hose life for added safety · High efficiency motor provides faster raising times · Easy servicing of hydraulic valve components · Controlled descent in case of severed hose - Safety first! Power Supply· The 5 hp electric motor will satisfactorily operate on any of the following 3 phase voltages: 208, 220, 230, 240, 440, 460, or 480. The model listed is the 36LL32. All other models are available. Custom configurations are also available. One Year - Electrical and Hydraulic Components and Hydraulic Cylinder Seals 1) Corporate Check or Cashier's Check Search for 100's of tools and test equipment through our "About Me" page Send an email to or click on "Ask seller a question." AP6.0 Shop With Confidence!Hayes Trading Co27W403 Chartwell, Winfield, IL Incorporated In The State Of Illinois Questions: Just send an email to or click on "Ask seller a question."Be sure to add us to your favorites list! Summary of My Selling Policies If we make an error in your order, request a return authorization (RA#) from us via email, fax, or phone. We will send you an approval notice for your return. Any merchandise authorized for return must be new, complete, and in saleable condition. A copy of our original invoice and the Return Authorization number (provided by us) must be included. Read my policies on my SquareTrade Seal |
