Subject: Alliant (bridgeport type) vertical mill, model rt-2V
(1) USED ALLIANT (BRIDGEPORT TYPE) VERTICAL MILL, MODEL RT-2V
Size: 9"x42"
T-Slots: (3) 5/8" on 2-1/2" Centers
X-Axis Longitudinal Travel: 30"
Y-Axis Cross Feed Travel: 12"
Knee Vertical Travel: 16"
Max. Table Height Above Floor: 47-1/4"
Max. Workpiece Weight: 750 Lbs.
Floor Area: 7 x 10 Feet
Max. Height: 82-1/16"
Net Weight: 1988 Lbs.
Spindle Drive: 2 HP, 3/69/220/440 V., A.C.
Ram Travel: 12"
Quill Travel: 5"
Spindle Nose to Table Top (Min): 2-1/2"
Spindle Center to Column (Min): 6-3/4"
Spindle Center to Column (Max): 18-3/4"
Swivel (Right/LEFT): 90 Degrees
Tilt (Up/Down): 45 Degrees
Horse Power: 2 HP
RPM: 1720
Taper: R-8
RPM.s Speed Range: Variable
Low 60 - 500
High 580 - 4500
Diameter: 1.875"
Quill Diameter: 3.375"
Low Revs.: 1.5 IPR
Medium Revs.: 3. IPR
High Revs.: 6. IPR
Original Scrapings Table and Knee
Inspect Under Power in our raritan Nj Warehouse
