#4A WARNER & SWASEY SQUARE-HEAD RAM-TYPE TURRET LATHE W/TAPER ATTACHMENT ON CROSS-SLIDE New 1973, Serial 2580178, Lot 583, Model 4A, M3550 9.3" Hole Thru Spindle - "Square-Head" Design Taper Attachment on Cross-Slide 24" 4-Jaw Chuck - 21 3-Jaw Chuck (2) Sliding Tool Holders - (2) Multiple Tool Holders (1) Flanged Tool Holder - 4-Way Tool Post Power Rapid Traverse - Coolant-Chip Pan & Conveyor Hole Thru Spindle...................... 9.3" Bar Capacity, Round.................... 9" Bar Capacity, Square................... 6.375" Bar Capacity, Hexagon.................. 7.75" Swing Over Bed Ways.................... 29.5" Swing Over Carriage Guard.............. 28.25" Swing Over Carriage Horn............... 22.44" Turning Length, Maximum................ 59.875" Carriage Longitudinal Travel (Z-Axis).. 68.375" Cross-Slide Cross Travel (X-Axis)...... 17" Turret Longitudinal Travel (Z-Axis).... 68.375" Spindle-Face to Turret, Maximum........ 80.19" (32) Spindle Speeds, Range............. 10 to 526 RPM (16) Carriage Longit Feeds (Z-Axis).... .005 to .167 IPR (16) Cross-Slide Cross Feeds (X-Axis).. .003 to .103 IPR (16) Turret Longitudinal Feed (Z-Axis). .005 to .167 IPR Main Motor, Horsepower/RPM............. 60/30 HP/1770/880 RPM Overall Dimensions, L x D.............. 17'10" x 7'9" Weight, Approximately.................. 21600 LBS PRICE: F.O.B. OUR WAREHOUSE........... $39,500.00 All machines/equipment subject to prior sale. |
