Subject: Ando AQ6331 portable optical spectrum analyzer
One-stop shop for your R&D, test and measurement applications in fiber communications, sensor and laser systems
Yokogawa AQ6331 Portable Optical Spectrum Analyzer
Test and measurement, optical instrument, sensor, DWDM
* Applicable fiber: Single mode fiber (10/125 µm)
* Wavelength range: 1200 to 1700 nm;
* Wavelength accuracy: ±0.02 nm (1520 to 1580 nm), ±0.05 nm (1580 to 1620 nm), ±0.3 nm (1200 to 1700 nm)
* Wavelength linearity: ±0.01 nm (1520 to 1580 nm), ±0.02 nm (1580 to 1620 nm)
Wavelength reproducibility 1) ±0.005 nm (1 min.)
* Wavelength resolution: 0.05 nm or less (Resolution setting: 0.05 nm, 1520 to 1620 nm),0.1 nm or less (Resolution setting: 0.1 nm, 1520 to 1620 nm)
* Resolution setting: 0.05, 0.1, 0.2, 0.5, 1.0 nm;
* Resolution accuracy: ≤ ±5 % (Resolution setting: ≤ 0.2 nm);
* Measurement level range: -90 to +20 dBm (1200 to 1600 nm, sensitivity: HIGH 3)
-80 to +20 dBm (1600 to 1700 nm, sensitivity: HIGH 3)
* Level accuracy: ±0.3 dB typ. (1550 nm, 1600 nm);
* Polarization dependency: ±0.05 dB (1550 nm, 1600 nm);
* Level linearity: ±0.05 dB (Input level: 0 to -50 dBm, sensitivity: HIGH 1 to 3);
* Level flatness: ±0.1 dB (1520 to 1580 nm), ±0.2 dB (1520 to 1620 nm)
* Level reproducibility: ±0.02 dB (1550 nm, 1600 nm)
* Dynamic range: 55 dB or more (1523 nm, peak: ±0.4 nm, resolution: 0.05 nm),
40 dB or more (1523 nm, peak: ±0.2 nm, resolution: 0.05 nm);
* Return loss 30 dB typ. (1550 nm, 1600 nm);
* Sweep time Approx. 0.5 sec.
(Span: 50 nm, sensitivity: NORMAL HOLD, number of sampling: AUTO, average: 1)
Functions Measurement condition Auto-configuration by auto-sweep sensitivity (NORMAL HOLD/AUTO, HIGH 1/2/3), averageing,
number of sampling, (11 to 20001, AUTO), sweep between markers, 0-nm sweep, pulse light measurement
Used, tested in excellent condition
