Specifications: Chucking capacity Swing over bed l9.69” Swing over cross slide l6.l4” Chucking part diameter maximum l7.72” Bar capacity (standard) 2.5” Axis Travel “X” Axis stroke - upper turret 9.06” lower turret 5.3l” “Z” Axis stroke - upper turret 20.47” lower turret l9.69” Spindle nose ASA-A2-8 Standard through hold 3.03 Spindle drive motor 40 HP Spindle spds(4ranges)l5-3000 RPM Infinite variable Rapid traverse rate “Z” Axis 400 IPM “X” Axis 200 IPM Turrets (2) l2 & 8 Stations Equipped with OSP CNC Control (l) 12” 3-Jaw Hydraulic Chuck Chip Conveyor Tail Stock Use the FREE Counters 1 million sellers do - Andale! |
