Leblond Makino MC86 Machining Center Spindle diameter 4 inches (100 mm) Spindle center line to table top 4-29 inches (100-735 mm) Spindle face to pallet center 8-33 inches (200-835 mm) Pallet size 24.8 x 24.8 inches (630 x 630 mm) Pallet weight 572 lbs (260 kg) Allowable load 2200 lbs (1000 kg) Pallet locating taper bushings at 4 pts. Locating repeatability .0002 inches (.005 mm) Pallet clamping 4 pt. hydraulic at 4400 lbs (2000 kg) Max tool length 15.75 inches (400 mm) Max tool weight 50 lbs (23 kg) Tool selection assigned pot, random access 16 inch Tsudacoma CNC rotary table Pallet change time approximately 20 seconds Power 460 Volts, 3 Phase, 60 Cycle * All items are subject to prior sale. All items are sold "AS - IS, Where - IS" and with all faults. Items are described to the best of our knowledge, however, We (Mikekandu and/or the Seller) make no guarantees regarding accuracy, errors or omissions in item descriptions and make no warranty, express or implied as to the nature, quality, value or condition of any item. We expressly disclaim any warranty of merchantability or fitness for a particular purpose of any item. For more information read our Frequently Asked Questions page. |
