Gray cnc vertical boring machine model vfr under power

UpUp


Subject: Gray cnc vertical boring machine model vfr under power
You are invited to purchase or "MAKE YOUR BEST OFFER" on a Gray CNC Vertical¬ Boring Machine with Automatic Tool Changer,¬ Model VFR that is presently busy producing¬ accurate parts for the Aero Space and Aircraft Industry.
Specifications of the Gray VFR CNC Vertical Boring Machine with Automatic Tool Changer:
Swing & Turning Diameter:¬ 52"
Turning Height Above Table:¬ 36"
Horizontal Travel of Ram (Right & Left):¬ 29" / 29"
Internal Clamping Diameter:¬ 36"
Chuck and Face Plate:¬ 48" dia. x 3.5" Thick
Rapid Travels (X,Y) 200 in/min.
Infinitely Variable Speeds:¬ 0.05 - 60 in/min.
Incremental Feed:¬ 0.01 - 10 in/min.
Vertical Movement of Cross Rail:¬ Fixed
Maximum Distance, Table Top to Rail Head:¬ 34"
Cross Section of Ram Head:¬ 7.5 x 7.5"
Tool Change Time:¬ 45 seconds
Toolholders Included with Purchase:¬ Approximate 8 pieces
Compensation Tool & Cutter Radius
Program Storage:¬ 22,000 Characters
Riser and Extra Table Pictured Included in Sale
We thank you in advance for your interest in this item and should you have any questions please feel free to ask them of us and we will try to answer them.
