Subject: Detroit 10 ton single ram vertical broach
(1) USED - 10 TON X 42" STROKE DETROIT MODEL VP-10-42 SINGLE RAM VERTICAL PULL DOWN BROACHING MACHINE WITH RETIEVER*
Serial No. M11 3995 New - 1969
Broaching Capacity - Normal 20,000 Lbs.
- Peak 30,000 Lbs.
Tool Slide Stroke - Normal 42"
- Minimum 6"
Maximum Variable Cutting and Return Speed 35 FPM
Throat Depth 8"
Working Height of Table and Above Platform 36"
Height of Operating Platform 16-1/2"
Vickers Pump Motor, Horsepower 30 HP, 1165 RPM (230/460)
Power System Oil Capacity 110 Gallons
Coolant Reservoir Capacity 229 Gallons
Overall Floor Space 140" F-B x 111" L-R x 126" H
Weight 20,000 Lbs.
Single Ram Configuration with Two Pullers
Allen Bradley Panel View SLC 500 PLC
Dual Pushbutton Master Control Station with Emergency Stop Button
Vickers Main Hydraulic System, Auxilliary Pump
*Preliminary Specifications Subject to Verification.
