Manufacturer: Frazier-Simples, Inc EXTREMLY HEAVY DUTY 9" DIA. SCREW BATCH CHARGER. S/N 3789-3-681. CONTRACT # 3789. UNIT WAS PREVIOUSLY USED FOR FEEDING GROUND GLASS CULLET INTO A FURNACE. 9" DIA. STAINLESS STEEL SCREW, ½" THICK FLIGHTING, SECTIONAL, CANTILEVER DESIGN. 3" DIA. SHAFT. CARBON STEEL HOPPER 34" X 24" X 24" TALL. 7.5 HP RELIANCE DUTY MASTER XE PREMIUM EFFICIENCY MOTOR, TEFC, 230/460 VOLT, 1.15 S.F., 213TC FRAME. APG GEAR REDUCER, T10TM7A, INPUT HP 11.9, OUTPUT RPM 16.5, 42,645 IN-LB. OF TORQUE, 105.9 RATIO, CHAIN DRIVE. OVERALL DIMENSIONS ARE 114" LONG X 27" WIDE X 53" TALL. FORK TRUCK SLOTS IN FRAMING. UNITS COME COMPLETE WITH MANUAL OPERATED STEEL DOLLYS WITH PUSH RODS AND CLAMP HANDLES. 8" STEEL WHEELS, V-GROOVE FOR RAIL MOUNT SYSTEM. MADE FROM 6" CHANNEL. DOLLY IS 25" WIDE X 66" LONG. MANUFACTURED BY FRAZIER-SIMPLEX, INC. (WE HAVE FOUR COMPLETE UNITS AVAILABE) CONTACT US IF YOU WOULD LIKE TO MAKE AN OFFER ON ALL FOUR (4) UNITS FOR ADDITIONAL ITEMS VISIT J&M INDUSTRIAL AT WWW.JMINDUSTRIAL.COM. |
