250 TON BLISS DUPLEX HYDRO-DYNAMIC MULTI-SLIDE New 1951, Serial No CN1612, ModelHS250H Four Post Tie Rod Construction With Two Opposing Rams (1) Up-Acting & (1) Down-Acting Ram "T" Slotted Bed & Ram - 5" Tie-Rods Tonnage Capacity........................ 250 TON Stroke Length Top Ram................... 12" Stroke Length Bottom Ram................ 6" Open Height............................. 34" Ram Diameters........................... 14.25" Upper Ram Area, L-R x F-B............... 25" x 25" Lower Ram Area, L-R x F-B............... 25" x 25" Hole Diameter Lower Platen.............. 8" Distance Between Posts, L-R x F-B....... 18" x 12" Ram Speeds, Rapid Advance............... 400 IPM (EACH) Ram Speeds, Pressing.................... 51 IPM Ram Speeds, Rapid Return................ 400 IPM (EACH) (2) Hydraulic Pump Motors............... 50 HP EACH Electrical System....................... 220-440/3/60 Overall Dimensions, W x D............... 5' x 7'6" Pit Required............................ 24" Overall Height.......................... 17' Weight, Approximately................... 37000 LBS CONDITION: Appears to be in Good Condition As Taken Directly from Government Stand-By Storage. NOTE: This Is A Duplex, Hydro-Dynamic, Hydraulic Sequence Controlled Multi-Slide Powdered Metal Press PRICE: F.O.B. OHIO (Toledo)............ $9,950.00 All machines/equipment subject to prior sale. |
