TURNING DIAMETERS:.........................13.78" MAX. TURNING LENGTHS:.............................35.00" MAX. MAX. SWING:.......................................21.65" CHUCK DIAMETER:..............................10.00" STD. NOSE:..................................................A2-8 BORE:..................................................3.15" SPEED:................................................3,800 RPM DRIVE MOTOR (HP):.............................30/20 INDEX INCREMENT (DEGREES):...........0.001 NOSE:.................................................A2-8 BORE:.................................................3.15" SPEED:...............................................3,800 RPM DRIVE MOTOR (HP):............................30/20 INDEX INCREMENT (DEGREES):..........0.001 TURNING:...........................................12 ROTARY:............................................12 HORSE POWER (30 MIN):...................9.5 RPM:..................................................4500 TURNING:...........................................12 ROTARY:............................................12 HORSE POWER (30 MIN):...................9.5 RPM:..................................................4500 TRAVEL:............................................10.63 INCH TRAVERSE RATE:..............................1181 IPM FEED RATE:......................................200 IPM TRAVEL:............................................6.30 INCH TRAVERSE RATE:.............................1024 IPM FEED RATE:......................................200 IPM TRAVEL:............................................9.06 INCH TRAVERSE RATE:.............................1181 IPM FEED RATE:......................................200 IPM ZA (STD): TRAVEL:............................................36.61 INCH TRAVERSE RATE:.............................1574 IPM FEED RATE:......................................200 IPM ZB (STD): TRAVEL:............................................36.22 INCH TRAVERSE RATE:.............................1574 IPM FEED RATE:......................................200 IPM TRAVEL:............................................37.01 INCH TRAVERSE RATE:.............................1574 IPM LNS QUICK LOAD SERVO S2 (.23" to 4.7" Diameter Bar) New price with options over $400,000 |
