#210-154 CINCINNATI-MILACRON "HYPOWERMATIC" HORIZONTAL-SPINDLE PRODUCTION MILL New 1961, Serial No 9B3P5K-5, Model 210-154, Ltr LR Flame Hardened Bed Ways - Coolant System Table Dimensions (Overall) W x L........ 15" x 83" Table Working Surface, W x L............ 15" x 76" Table Longitudinal Travel (X-Axis)...... 48" Spindle-Head Vertical Travel (Y-Axis)... 10" Quill Cross Adjustment (Z-Axis)......... 3" Quill Diameter.......................... 7" Spindle Taper........................... #50 NSTD (16) Spindle Speeds, Range.............. 50 to 2000 RPM Longitudinal Table Feeds, Range......... 1/4 to 20 IPM Power Rapid Table Traverse.............. 300 IPM Spindle Motor, Horsepower............... 10 HP Feed Drive Motor, Horsepower............ 3 HP Overall Dimensions, L x D............... 10' x 8' Overall Height.......................... 5'11" Weight, Approximately................... 15000 LBS PRICE: F.O.B. OUR WAREHOUSE............ $2,450.00 All machines/equipment subject to prior sale. |
